Explosion-proof distribution panel MAMX-02/03

* Enclosure material: Aluminium alloy ZL102;

* Ex-marks:

MAMX-02:Ex db IIB+H2 T6...T4 Gb; Ex tb IIIC T80°C...T135°C Db IP66   MAMX-03:Ex db IIC T6...T4 Gb; Ex tb IIIC T80°C...T135°C Db IP66

* Certificate:ATEX,IECEx and TR CU

*Max Current:1500A

*Max Power consumption:800W

Description

Explosion-proof Distribution Panel MAMX-02 and MAMX-03

* In-built circuit breaker, AC Contactor, Thermorelay, PLC, Transducer, Soft starter and other components, The panel can install indicator, Pushbutton, Universal switch, Display instrument.

* Cable entry

* Used in chemical, oil refining, oil exploitation, offshore oil platforms, oil tankers, military and other hazardous areas.

* Suitable for controlling the temperature maintenance and the power supply of electric heating in the anti-freezing in hazardous area; Adopting different instruments and program control modules to control the temperature of the heating object so as to meet the requirements of different customers;

* Different installation methods such as hanging and floor-mounted installation and different incoming cables such as ordinary rubber and plastic cable, armored cable and heating cable.
