Explosion-proof Temperature Control Box MAMX-12-C2

*Enclosure material:Aluminum Alloy ZL102

*Enclosure dimension:161*161*109mm

*Ex mark: Ex db IIC T6...T4 Gb; Ex tb IIIC T80°C...T135°C Db IP66

*Certificate:ATEX, IECEx, TR CU

Description

Explosion-proof Temperature Control Box MAMX-12-C2

*Rated current: <40A

*Built in components: temperature-controller, silicon controlled

*Used in chemical, oil refining, oil exploitation, offshore oil platforms, oil tankers, military and other hazardous areas;

*Suitable for controlling the heat tracing system used in anti-freezing in hazardous areas; can respond to changes in ambient temperature and can adjust the set point;

*Can be used to control a single heat tracing circuit or as a contactor to switch the signal control of multiple heat tracing circuits;

*Different installation methods such as hanging, embedded, heat tracing bracket installation and different incoming cables such as ordinary rubber and plastic

cable, armored cable and heating cable are optional.




Ex Temperature Control Switch MAMX-12-C2
